Home Lighting License Lighting 36 SERIES FLEXITE SIDE LICENSE LAMP 10-30 VOLT

36 SERIES FLEXITE SIDE LICENSE LAMP 10-30 VOLT

PART TRU36042C
SUPPLIER ---
SUPPLIER PART # ---
Calculating price...
QUANTITY

About this item

36 Series, LED, 1"x2", Rectangular, Clear, 3 Diode, Black, Bracket Mount , .180 Bullet, License Light

Provides license lamp solution that requires no mounting brackets or installation screws;;Lamp adheres directly to mounting surface through use of heavy-duty adhesive backing, with an easy-to-install, peel-off liner;;Gray and black brackets are only for rear exit wire lamp, (36140C), and are available if preferred over surface mounting;;OmniVolt;;Hardwired with rear and side exit wires complete with 180 degrees

  • Provides license lamp solution that requires no mounting brackets or installation screws
  • Lamp adheres directly to mounting surface through use of heavy-duty adhesive backing, with an easy-to-install, peel-off liner

There are currently no resources for this product.

Lens Shape Rectangular
Total Width In INH 1.88
Housing Material Polycarbonate
Packaging Type Standard
Voltage (VLT) 12
Plug Side Two .180 Bullet
Weight In LB 0.09
Series 36 Series
Sealed/Bulb Replaceable Sealed
Brand Truck-Lite
Lighting Technology LED
Compliance Family R4
Mount Type Bracket Mount
Mount/Trim Color Black
Total Depth In INH 0.75
Kit Kit (Yes/No)
Lens Color Clear
Kit (Yes/No) Kit (Yes/No)
Lens Material Polycarbonate
Current_AMP 0.05
Lamp Connection Hardwired
Taxonomy Lights.License Lights
Total Depth In MMT 19.05
Total Height In MMT 13.21 MM
Plug Side One Hardwired
Product Subgroup License Light
Product Group Back Up & License Lighting
Lens Height_INH 0.56 IN
Total Width In MMT 47.75
Number of Wires 2
Lens Width_INH 1.5 IN
Total Height In INH 0.52
Number of Diodes/Bulbs 3
Common Size 1"x2"
Standards Met R4
Mount/Trim Material Polycarbonate
