Home Braking System ABS & Stability (ABS) (RSS+) ABS Lighting 19 SERIES "ABS" LAMP

19 SERIES "ABS" LAMP

PART TRU19205Y
SUPPLIER TruckLite
SUPPLIER PART # 19205Y
Calculating price...
QUANTITY

About this item

19 Series, Incandescent, 1"x4", Rectangular, Yellow, 2 Diode, Bracket Mount, Marker & Clearance Light

Designed to fit in limited mounting areas;;Fits in most narrow header rails;;Can be mounted vertically or horizontally;;Snap-lock tabs allow quick and easy installation;;Suitable for PC requirements on a 45-degree angle when using base mounts on page 137;;Replaces Signal-Stat 1900 series

  • Designed to fit in limited mounting areas
  • Can be mounted vertically or horizontally
  • Fits in most narrow header rails
  • Snap-lock tabs allow quick and easy installation

There are currently no resources for this product.

Color Yellow
Lens Shape Rectangular
Total Width In INH 3.78
Housing Material Polycarbonate
Packaging Type Standard
Voltage (VLT) 12
Plug Side Two No Plug
Weight In LB 0.1
Series 19 Series
Sealed/Bulb Replaceable Sealed
Brand Truck-Lite
Lighting Technology Incandescent
Mount Type Bracket Mount
Total Depth In INH 0.83
Lens Color Yellow
Kit (Yes/No) Kit (Yes/No)
Lens Material Polycarbonate
Lamp Connection 19 Series Male Pin
Total Depth In MMT 21.08
Total Height In MMT 31.24 MM
Plug Side One 19 Series Male Pin
Product Group Marker & Clearance Lighting
Lens Height_INH 1.23 IN
Total Width In MMT 96.01
Lens Width_INH 3.78 IN
Total Height In INH 1.23
Number of Diodes/Bulbs 2
Common Size 1"x4"
Standards Met P2
