Belt Configuration
12PK
Stud Thread Size
.375-24 UNF IN
Bolt Circle
3.5 IN
Fan Pilot Diameter
2.56
Heavy Duty
True
Belt Groove Location
1.476377953 IN
Fan Blade Stud Length
1.066929134 IN
Vertical Mounting Distance
8.13
Center of JB To Top Right Mounting Hole
2.819291339 IN
Horizontal Mounting Distance
2.36
Overall Length
6.888976378 IN
Back Pulley Diameter
6.26
Fan Bolt Circle
3.5
