Supply Port 2
1/2-14 NPT
Mounting
.96 IN x .40 IN Slot (4x)
Body Configuration
2 SUP / 4 DEL (2H + 2V)
Minimum Operating Temperature
-40 degF (-40 degC)
Net Weight
1.275 KG
Delivery Port 5
Not applicable to this part
Delivery Port 6
Not applicable to this part
Delivery Port 3
3/8-18 NPT
Delivery Port 4
3/8-18 NPT
Product Width
102.0 CM
Delivery Port 1
1/2-14 NPT
Delivery Port 2
1/2-14 NPT
Control / Secondary Service Port
1/4-18 NPT
Mounting Orientation (CW from Front Face)
Not applicable to this part
Delivery Port 7
Not applicable to this part
Delivery Port 8
Not applicable to this part
Supply Port 1
1/2-14 NPT
Mounting Bracket Direction
Not applicable to this part
Maximum Operating Temperature
200 degF (93 degC)
Crack Pressure
5.5 PSI
Harmonized Schedule (HS) Code
848120
Control Port Orientation (CW from Front Face)
Not applicable to this part
Internal Supply Passage to Cover
Not applicable to this part
Mounting Bracket Location
Loose in Box
TMC Washer
RV055
Product Height
98.0 CM
Product Length
102.0 CM
Cautionary Note(s)
Not applicable to this part
Exhaust Port
Dust Shield
Market Indicator
Aftermarket New
Balance / Primary Service Port
Not applicable to this part
Unit of Dimension
CM
