Stop Light Switch Port
Not applicable to this part
Mounting
O .35 IN (2x)
Tractor Protection Port
1/4-18 NPT
Minimum Operating Temperature
-40 degF (-40 degC)
Net Weight
0.338 KG
Trailer Service Quick Release
Not applicable to this part
Trailer Service Port
1/2-14 NPT
Product Width
51.562 CM
Tractor Protection Port (Firewall)
Not applicable to this part
Stop Light Switch Port (Firewall)
Not applicable to this part
Vent
No
Mounting Type
Cab / Chassis
Service Line Opening Pressure
35 +- 5 PSI
Auxiliary Supply Port
Not applicable to this part
Trailer Supply Port
1/2-14 NPT
Maximum Operating Temperature
200 degF (93 degC)
Tractor Service Port
3/8-18 NPT
Trailer Supply Quick Release
Not applicable to this part
Tractor Control Port (Primary)
Not applicable to this part
Harmonized Schedule (HS) Code
848120
Tractor Control Port (Secondary)
Not applicable to this part
Trailer Control Port
Not applicable to this part
Product Height
65.024 CM
Product Length
120.65 CM
Service Line Shut-Off Pressure
25 +- 3 PSI
Exhaust Port
Dust Shield
Market Indicator
Aftermarket New
Unit of Dimension
CM
